Jack-up, O&K Jack-up Series

O&K Jack-up Series

The specific design of the O&K Jack-up Series has been assessed by ABS to work in lifting and lowering legs and hulls of drilling and service jack up rigs, lift boats and windmill installation vessels. Units can be in-line or have a drop box for offsetting the motor installation. They can be electrically or hydraulically driven, with or without a negative parking brake. These jack-up drives can deliver integrated pinions from m50 to m100 and lantern pieces with integrated torque arm for easy installation. Units have class approval from ABS and DNV GL, and full 3.2 certification of the load-bearing parts of the gear transmission with full traceability from raw material to final machined component.

Specifications

Torque Range

Applicable motors

Piston hydraulic motors
Electric motors IEC

Types & Powers

MAX JACKING

Up to 1,900 kNm

MAX HOLDING

Up to 2,400 kNm

STORM HOLDING

Up to 2,900 kNm

Downloads

Product Range Catalogue- O&K
Catalogues

EN

Download

Brochure Marine & Offshore
Catalogues

EN

Download
