Using an integrated solution, rather than a traditional gearhead/motor combination, the BMS series offers revolutionary space-saving machine design, a wider range of options and a superior performance due to the synergies between permanent magnets, synchronous motors and precision planetary gearbox technologies. With very reliable tested features, the customer has the flexibility to select three types of performance with an excellent combination variants low overspeed, medium overspeed and high overspeed. All these variants have been designed to optimize the output needed with the benefits of supreme compactness, highest torque / input speed and optimization of drive size. These excellent benefits are achieved using 5 gearbox sizes and 14 motors in combination with 3 types of Yarn Winding machines. Excellence and reliability allow continuous duty to run your application safely.

Specifications

  • Main options

    Additional flywheel (optional)
    0. 5 ... 70 (Kgm2 x 10-4)
  • Feedback

    • Resolver 2-pole resolver 8kHz & 10 kHz
    • Optical encoder EnDat single & multi turn
    • Optical encoder Hiperface single & multi-turn
    • Capacitive encoder Hiperface single & multi-turn
  • Temperature sensor

    PTC
    KTY 84-130
    PT1000
  • Sizes

    5 sizes
    BMS 060; 070; 090; 130; 160
  • Torque range

    45 ... 1200 Nm (398 … 10,620 in-lb)
  • Degree of protection

    IP65
  • Certifications

    CE
  • Power supply & Power range

    230, 400 Vac
  • Brake options

    Holding brake (optional)
    24 Vdc
  • Installation length

    157 .. 486 mm
  • Lubrication

    Life lubricated
    Optionally food grade oil
  • Operation

    Continuous duty
    Cyclic operation
  • Out put speed

    50 ¦ 1500 rpm
  • Motors

    14 motors with 3 types of Yarn Winding machines
    3000 rpm; 4500; 6000 rpm
    065A; 065B; 082B; 082C; 102A; 102B; 102C; 118A; 118B; 118C; 145B; 145C; 170B; 170C

Key features

Quiet running

Universal design allowing any mounting orientation
