MPEK
The MPEK series offers medium levels of performance and position accuracy at a competitive value-price ratio. The output design in line with market standards ensures great compatibility for easy retrofi ts and a high level of freedom in projects development. Its right angle-design allows more compactness for space-saving layouts.
key features
Great price-performance ratio
Designed for continuous duty and intermittence duty
High compatibility for easy retrofits
Suitable for a variety of applications thanks to great flexibility
Right-angle design for space-saving layouts
Specifications
Torque range
159.3 ... 2,655 lb-in
Stall Torque Range
Graphic description
| Type | Nominal Torque (Nm) |
|---|---|
| MPEK 060 | 30 |
| MPEK 080 | 65 |
| MPEK 120 | 155 |
Sizes
060, 080, 120
Gear ratios
• 2 stages: 3 ... 10
• 3 stages: 9 ... 100
• 3 stages: 9 ... 100
Max radial force
220 ... 2,000 N
Degree of protection
IP54
Input speed
Up to 6,000 min-1
Torsional stiffness
2.5 ... 23.4 Nm/arcmin
Lubrication
Standard; Food grade
Output
Smooth keyless shaft; keyed shaft
Specifications
Torsional backlash
• 2 stages: less than 7 arcmin
• 3 stages: less than 9 arcmin
• 3 stages: less than 9 arcmin
Input
Motor adapter; Solid input shaft; Without motor adapter
