The synchronous reluctance motor guarantees a sustainable ecological solution which decreases the total environmental impact thanks to the absence of magnets and increased efficiency. Reduced operating costs allow a fast return. This product benefits from the proven simplicity and reliability of induction motors and the higher efficiency of synchronous motors.

Specifications

  • SIZES

    HIGH EFFICIENCY PACKAGE
    71B ... 132 MB

    HIGH OUTPUT PACKAGE
    71B ... 132 MB
  • power supply

    400 Vac
  • Key benefits

    Both Bonfiglioli packages are IES2 according to the International Efficiency of Systems (IES) classification for the drive and motor combination (IEC 61800-9-2).
  • Main options

    Thermal protection
    Silicon sensor KTY 84-130
    Thermistor PTC 150
    Platinum sensor PT1000
    Forced ventilation
    Power supply 1 phase 230V (frame 71-100) 3-400V Y (frame 112-132)
    Double extended shaft
    External mechanical protection
    Rotor balancing grade B
  • Degree of protection

    IP55
    IP56 (optional)
  • Motors

    HIGH EFFICIENCY PACKAGE
    Rated motor power
    0.37 ... 9.2 kW

    HIGH OUTPUT PACKAGE
    Rated motor power
    0.55 ... 18.5 kW
  • Motor options

    Motor mounting
    B3; B5; B14

Key features

Highly accurate sensorless control technology

Compact, economical & eco-friendly

Energy savings

High reliability

High performance solution

Applications
